Description
This machine has been developed for determining the resistance to abrasion/wear of natural stones and concrete products. Easy to use, electronic control of the disc speed with auto shut-off of the machine at the selected number of revolutions. The abrasion disk wheel is 70 mm thick. Supplied complete with 5 kg of white corundum FEPA grit size 80 and calibration sample (Boulonnais marble).
The machine can also be converted, by the conversion kit 48-D0471/K, for abrasion test conforming to EN 1344, 10545-6, 14617-4, 12808-2, UNE 127024.
See accessories.
The standard version conforms to EN 1338, 1339, 1342, 14157, 1340, 1341.
Technical Specs
- Power: 500 W
- Overall dimensions: 620x670x850 mm
- Weight approx.: 85 kg
Accessories
48-D0471/K
Conversion kit to perform the abrasion test conforming to EN 1344, 10545-6, 14617-4, 12808-2, UNE 127024. Comprising counterweight, hopper , abrasion disk dia. 200 x 10 mm and silica calibration plate.
Spare parts
48-D0471/1
Abrasive white corundum sand 80 grade. Pack of 25 kg.
