Sulphur Capping Equipment for Cylinders

When testing concrete cylinder specimens, it is essential that the two ends are perfectly flat. This range of equipment allows the ends of the various sizes of concrete cylinders or cores to be capped using the sulphur capping compound.

55-C0121/23 – Capping Jig 100mm dia
Used to assure plane end surfaces perpendicular to the axis of the cylinder during the capping. Base machined from steel. Other sizes available.

55-C0121/37A – Sulphur Capping Compound 20kg
The compound is a mixture of sulphur and mineral filler to give a high finish and performance.

55-D1403 – General Purpose Melting pot
Used to melt the capping compound. The temperature is set and maintained at the desired value. Adjustable electronic thermoregulator and pilot lamp fully isolated conforming to CE requirement.

Capacity: 5l approx.
Temperature range: from +30 to 150°C
Power: 700 W
Dimensions:
internal 200 mm dia.160 mm depth
external 285 mm dia.x 275 mm high
Weight approx.: 2.7 kg
