Description
50-C0920/FR 150 kN cap. flexure frame complete with rollers, pressure transducer and connection kit for connection to control consoles. Pedestal available as accessory.
A simple and practical frame developed for testing on standard concrete beams. The distance of both pair of loading and support rollers can be easily adjusted: one of the two upper rollers can be removed and the other placed in the centre for centre point loading test.
Technical Specs
| Max. load capacity kN | 150 |
| Load sensor | Pressure transducer |
| Max. vertical clearance mm | 158 |
| Horizontal clearance mm | 185 |
| Roller size mm | 40 dia. x 160 long |
| Distance between upper rollers mm | 150, 100 or single roller |
| Distance between lower rollers mm | 450 and 300 |
| Piston travel mm | 75 |
| Overall dimensions (lxwxh) mm, frame only | 455 x 560x 960 |
| Overall dimensions (lxwxl) mm, including pedestal | 455 x 560x 1575 |
| Weight approx. kg, frame only Including pedestal |
150 173 |
Accessories
50-C0920/B
Frame pedestal, 455x465x 615 mm (W x L x H), Weight 23 kg.
50-C0920/1
Compression platens dia.165x30mm
50-C0920/2
Piston travel limit switch
