Description
This machine, used to compact the 40x40x160 mm cement prisms in the mould, has been developed to fulfill precisely the EN and ISO standards. Each single requirement as, for example, weigh distribution, dimensions, structural design and working cycle is individually checked and verified.
Prism moulds, feed hopper, scrapers and glass plate are not included and have to be ordered separately. See accessories.
Technical Specs
- Highly rigid structure, joints between main parts (table – arms – base) easily removable to check weights
- Drop height: 15 mm. Since the mechanical parts are subject to wear and tear and this height tends to change with use, the hammer has an adjustable height, making it possible to restore the initial drop height
- Motor: power: 250 W, 60 r.p.m.
- High resolution graphical display 128×80 pixels and 6 keys membrane keyboard
- 8 languages can be set: Italian, English, French, Spanish, Polish, Portuguese, Romanian and Cesky
- Double test procedure: it is possible to set the target revolutions / drops or the total working time
- Overall dimensions (lxdxh): 310x1000x385 mm
- Weight approx.: 55 kg
Accessories
65-L0011
Feed hopper to fit the three-gang mould on the 65-L0012/G apparatus
65-L0010/A1
Pair of scrapers: small and large
65-L0010/A2
Glass plate 210x185x6 mm
