Water and Dust Proof IP65 Compliant
Description
High degree of usability – For more efficient weighing operation
User-friendly key configurations, reasonable menu-tree and short stabilization time make possible the efficient and comfortable weighing operation.
High durability in precision weighing enabled by Tuning-fork sensor
Innovative and heavy-duty tuning-fork sensor provides everlasting excellent performance in precision weighing in various manufacturing processes.
Water-proof structure, easy to clean
Because both of platform and indicator are made from stainless steel they are highly resistant to physical shocks and chemical materials. Easy to clean by water after operation.
Dust-proof structure, highly resistant to severely dusty environment
IP65 dust-proof structure ensures reliable weighing results even in severely dusty environment.
Pole style with optional kit
Optional pole kit is available.
Under Balance Weighing
Under hook facility available as option.
Technical Specifications
- IP protection rating 65
- OIML & EU approval class 11
- Measuring system: Tuning-fork vibration method
- Power supply: Dedicated AC adapter (100-240 VAC, 12 VDC)
- Output: RS232C （D-sub ９P)
- Display: Dual LCD display with backlit
- Scale cable length: 1m (extended to 5m or 10m as factory option)
- Weight: External weight type 18kg, Internal weight type 19kg
|
VIBRA Model name |
HJ22KSR | HJ33KSR |
HJ62KSR |
|
| Capacity |
22kg |
33kg | 6200g |
62kg |
| Readability (d) |
0.1g |
0.1g | 0.1g |
1g |
| Verification intervals (e) |
1g |
1g |
1g |
|
| Non-linearity |
±0.3g |
±0.3g | ±0.3g |
±3g |
| Repeatability (σ) |
0.1g |
0.1g | 0.1g |
1g |
| Pan size | 400 x 350 mm | |||
| Dimension (LDH) | 350 x 482 x 175mm (350 x 482 x 700mm when pole option installed) | |||
| Calibration | With internal and external weight | |||
Downloads
Brochure (PDF)
Ordering Information
| 11-W8002.LOC | Balance VIBRA HJK series 22kg x 0.1g |
| 11-W8003.LOC | Balance VIBRA HJK series 33kg x 0.1g |
| 11-W8004.LOC | Balance VIBRA HJK series 62kg x 0.1/1g |
Accessories
| 11-W8000/1.LOC | Pole Display VIBRA HJK series |
| 11-W8000/2.LOC | Under Balance Weighing Hook VIBRA HJK series |
