Description
UNIFLEX 300 flexural frame has been designed to satisfy the stringent requirements prescribed by the standards concerning, above all, the determination of deformability and ductility index of sprayed concrete and fiber reinforced concrete. The “C” shaped open structure allows an easy and practical front loading but, once the specimen is in the loading position, the structure is closed by a vertical rod hydraulically clamped and controlled to compensate frame deformation during the test thus ensuring high rigidity.
Fitted with high precision strain gauge load cell for accurate and reliable test results. The frame has to be connected to a control console and completed with the suitable testing accessories depending on the test to be performed.
Technical Specs
- Max. load capacity: 300 kN
- Load sensor: high precision load cell
- Piston travel: 110 mm
- Max. Vertical daylight (without accessories): 546 mm
- Max. vertical daylight with accessories:
- 50-C1601/1: 263 mm
- 50-C1601/1B: 285 mm
- 50-C1601/2: 263 mm
- 50-C1601/3: 221 mm
- 50-C1601/4: 350 mm
- 50-C1601/6: 128 mm
- 50-C1601/7: 110 mm
- Horizontal daylight (between uprights) : 900 mm
- Min./Max. distance between lower bearers: adjustable from 80 to 1500 mm
- Min./Max. distance between upper bearers: adjustable from 80 to 500 mm
- Overall dimensions (lxwxh) : 1700x1266x1512 mm
- Weight approx.: 605 kg
- Note: Using the accessories 50-C1601/1B, 50-C1601/2, 50-C1601/3, 50-C1601/4, the accessory 50-C1601/KIT must be used. See accessories.
